About this item:
For over ten years, our tow dollies have been a top choice for RVers and folks searching for premium car tow dollies online, our new
STOW and GO FOLDING
Featuring a robust steel frame, swivel tire pan, and a fold-and-store design, makes traveling with a second vehicle a pleasurable proposition.
Construction:
We built our 670-lb folding car tow dolly with heavy-duty galvanized steel. The process of galvanizing involves coating the steel in layers of zinc. For buyers, this means you’re getting a trailer that’s hardwearing, rust-resistant, and one heck of a head-turner.
Additionally, we equip the tow dolly with a swivel pan to relieve stress on the vehicle-in-tow’s front end. Instead of engaging the vehicle-in-tow’s steering box when turning, the swivel pan does the work.
Fold and Store:
unique design provides a space-saving solution by allowing the user to transform the car tow dolly from 132.5 inches length extended to just 72 inches folded. How? Just fold up the ramps; remove the clevis pin from the tongue, and use the swivel wheel on the trailer jack to roll the tongue towards the tow dolly’s fender. That’s a size reduction of nearly 50 percent. And that’s space you can use for something else in your driveway, garage, or RV lot.
Hydraulic Surge Brakes:
In most states, brakes and an emergency breakaway system are required by law. So, it fit with every drum brakes and a Demco actuator (includes a breakaway cable). These are standard equipment on our foldable car tow dolly at
no additional charge
.
Features:
Integrated folding ramps
Folding tongue
72″ folded length—
reduced footprint saves space and money at RV lots
3,500 lb Maximum over-the-axle weight
Trailer tongue jack with swivel wheel—
included
Tongue handle for easy moving, coupling, and uncoupling
2″ Ball coupler
2 Safety chains
Integrated, adjustable winches—
MAXIMUM
ease-of-use
Hydraulic surge brakes
Drum brakes
Demco DA66 actuator
Emergency breakaway system
14″ Steel wheels
Sturdy steel fenders
—silver powder-coated
Tilting swivel pan—
easy loading
2 Redundant security chains for added peace of mind—
DOT approved LED taillights—
LED lights last longer than incandescent bulbs
Low-weight, high-strength tubular steel construction—
tow your second vehicle with confidence
4-pin flat connector—
factory molded
Premium galvanized finish—
ensures rust-free protection for years to come
Specifications:
Empty Weight 670 lb
Maximum Over-the-Axle Weight 3,500 lb
Maximum Vehicle-in-Tow Curb Weight 4,900 lb
Coupler: 2”
Finish: Galvanized
6,500-lb-rated Lashing Winches
12,000 lb Rated Tire Nets (Free straps included)
Dual Safety Chain Set
Heavy Duty Spindles & Cast Hubs w/ Easy-Lube Hub
Tires: 14” Heavy Duty
DOT Approved Lighting
Pre-Wired Factory Wiring Harness
Demco Actuator and Emergency Breakaway System (hydraulic surge brakes)
LED Taillights
Maintenance-Free Teflon Pads for Easy Turning Pan
Tire Pan Width : 79 1/2 in. maximum width / 43 3/4 in. minimum width
Requirements: Flat 4-Pin Connector / 2″ Ball / 18″ Tongue Height
